SPECIFICATIONS
Brand Name: XHCRF
Hign-concerned Chemical: None
Gain(dB): 2.5dBi
Origin: Mainland China
Certification: none
Electrical Specification |
Mechanical Specification |
||
Frequency/ Band |
433MHz |
Connector |
IPEX-1/Connecting by welding |
Gain |
2dBi/2.5dBi/3dBi |
Net Weight |
1~4g |
VSWR |
≤1.5 |
Antenna Material |
PCB/ FPC |
Polarization |
Vertical |
Cable Type |
RF1.13 |
Radiation Direction |
Omnidirectional |
Cable Length |
57mm-111mm |
Input Impedance |
50Ω |
Working Temperature |
-30℃~+70℃ |
Power |
2W/5W |
Storage Temperature |
-30℃~+70℃ |
